25

Dalton’s law of partial pressures may be used to relate measured gas pressures for gaseous mixtures to their compositions. Diffusion is the process whereby gaseous atoms and molecules are transferred from regions of relatively high concentration to regions of relatively low concentration. Effusion is a similar process in which gaseous species pass from a container to a vacuum through very small orifices. The rates of effusion of gases are inversely proportional to the square roots of their densities or to the square roots of their atoms/molecules’ masses (Graham’s law). The concentration of a gaseous solute in a solution is proportional to the partial pressure of the gas to which the solution is exposed, a relation known as Henry’s law.

- State Dalton’s law of partial pressures and use it in calculations involving gaseous mixtures

Unless they chemically react with each other, the individual gases in a mixture of gases do not affect each other’s pressure. Each individual gas in a mixture exerts the same pressure that it would exert if it were present alone in the container (Figure 25.1). The pressure exerted by each individual gas in a mixture is called its partial pressure. This observation is summarized by Dalton’s law of partial pressures: *The total pressure of a mixture of ideal gases is equal to the sum of the partial pressures of the component gases*:

$${P}_{Total}={P}_{A}+{P}_{B}+{P}_{C}+\mathrm{...}={\text{\Sigma}}_{\text{i}}{P}_{\text{i}}$$

In the equation *P _{Total}* is the total pressure of a mixture of gases,

The partial pressure of gas A is related to the total pressure of the gas mixture via its mole fraction (*X*), a unit of concentration defined as the number of moles of a component of a solution divided by the total number of moles of all components:

$${P}_{A}={X}_{A}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{P}_{Total}\phantom{\rule{2em}{0ex}}\text{where}\phantom{\rule{2em}{0ex}}{X}_{A}=\phantom{\rule{0.2em}{0ex}}\frac{{n}_{A}}{{n}_{Total}}$$

where *P _{A}*,

(a) What are the partial pressures of each of the gases?

(b) What is the total pressure in atmospheres?

$${P}_{{\text{H}}_{2}}=\phantom{\rule{0.2em}{0ex}}\frac{\left(2.50\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22123}}\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol}}\right)\left(0.08206\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}\phantom{\rule{0.2em}{0ex}}\text{atm}\phantom{\rule{0.2em}{0ex}}\overline{){\text{mol}}^{\text{\u22121}}\phantom{\rule{0.2em}{0ex}}{\text{K}}^{\text{\u22121}}}\right)\left(308\phantom{\rule{0.2em}{0ex}}\overline{)\text{K}}\right)}{10.0\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}}\phantom{\rule{0.2em}{0ex}}=6.32\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22123}}\phantom{\rule{0.2em}{0ex}}\text{atm}$$

$${P}_{\text{He}}=\phantom{\rule{0.2em}{0ex}}\frac{\left(1.00\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22123}}\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol}}\right)\left(0.08206\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}\phantom{\rule{0.2em}{0ex}}\text{atm}\phantom{\rule{0.2em}{0ex}}\overline{){\text{mol}}^{\text{\u22121}}\phantom{\rule{0.2em}{0ex}}{\text{K}}^{\text{\u22121}}}\right)\left(308\phantom{\rule{0.2em}{0ex}}\overline{)\text{K}}\right)}{10.0\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}}\phantom{\rule{0.2em}{0ex}}=2.53\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22123}}\phantom{\rule{0.2em}{0ex}}\text{atm}$$

$${P}_{\text{Ne}}=\phantom{\rule{0.2em}{0ex}}\frac{\left(3.00\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22124}}\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol}}\right)\left(0.08206\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}\phantom{\rule{0.2em}{0ex}}\text{atm}\phantom{\rule{0.2em}{0ex}}\overline{){\text{mol}}^{\text{\u22121}}\phantom{\rule{0.2em}{0ex}}{\text{K}}^{\text{\u22121}}}\right)\left(308\phantom{\rule{0.2em}{0ex}}\overline{)\text{K}}\right)}{10.0\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}}}\phantom{\rule{0.2em}{0ex}}=7.58\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22124}}\phantom{\rule{0.2em}{0ex}}\text{atm}$$

The total pressure is given by the sum of the partial pressures:

$${P}_{\text{T}}={P}_{{\text{H}}_{2}}+{P}_{\text{He}}+{P}_{\text{Ne}}=\left(0.00632+0.00253+0.00076\right)\phantom{\rule{0.2em}{0ex}}\text{atm}=9.61\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\text{\u22123}}\phantom{\rule{0.2em}{0ex}}\text{atm}$$

1.137 atm

Here is another example of this concept, but dealing with mole fraction calculations.

(a) What are the mole fractions of O_{2} and N_{2}O?

(b) What are the partial pressures of O_{2} and N_{2}O?

For O_{2},

$${X}_{{O}_{2}}=\phantom{\rule{0.2em}{0ex}}\frac{{n}_{{O}_{2}}}{{n}_{Total}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\text{2.83 mol}}{\left(2.83+8.41\right)\phantom{\rule{0.2em}{0ex}}\text{mol}}\phantom{\rule{0.2em}{0ex}}=0.252$$

and ${P}_{{O}_{2}}={X}_{{O}_{2}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{P}_{Total}=0.252\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\text{192 kPa}=\text{48.4 kPa}$

For N_{2}O,

$${X}_{{N}_{2}O}=\phantom{\rule{0.2em}{0ex}}\frac{{n}_{{N}_{2}O}}{{n}_{\mathrm{Total}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\text{8.41 mol}}{\left(2.83+8.41\right)\phantom{\rule{0.2em}{0ex}}\text{mol}}\phantom{\rule{0.2em}{0ex}}=0.748$$

and

${P}_{{N}_{2}O}={X}_{{N}_{2}O}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{P}_{\mathrm{Total}}=0.748\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\text{192 kPa}=\text{144 kPa}$

1.87 atm

A simple way to collect gases that do not react with water is to capture them in a bottle that has been filled with water and inverted into a dish filled with water. The pressure of the gas inside the bottle can be made equal to the air pressure outside by raising or lowering the bottle. When the water level is the same both inside and outside the bottle (Figure 25.2), the pressure of the gas is equal to the atmospheric pressure, which can be measured with a barometer.

However, there is another factor we must consider when we measure the pressure of the gas by this method. Water evaporates and there is always gaseous water (water vapor) above a sample of liquid water. As a gas is collected over water, it becomes saturated with water vapor and the total pressure of the mixture equals the partial pressure of the gas plus the partial pressure of the water vapor. The pressure of the pure gas is therefore equal to the total pressure minus the pressure of the water vapor—this is referred to as the “dry” gas pressure, that is, the pressure of the gas only, without water vapor. The vapor pressure of water, which is the pressure exerted by water vapor in equilibrium with liquid water in a closed container, depends on the temperature (Figure 25.3); more detailed information on the temperature dependence of water vapor can be found in Table 25.1, and vapor pressure will be discussed in more detail in the chapter on liquids.

Vapor Pressure of Ice and Water in Various Temperatures at Sea Level

Temperature (°C) | Pressure (torr) | Temperature (°C) | Pressure (torr) | Temperature (°C) | Pressure (torr) | ||
---|---|---|---|---|---|---|---|

–10 | 1.95 | 18 | 15.5 | 30 | 31.8 | ||

–5 | 3.0 | 19 | 16.5 | 35 | 42.2 | ||

–2 | 3.9 | 20 | 17.5 | 40 | 55.3 | ||

0 | 4.6 | 21 | 18.7 | 50 | 92.5 | ||

2 | 5.3 | 22 | 19.8 | 60 | 149.4 | ||

4 | 6.1 | 23 | 21.1 | 70 | 233.7 | ||

6 | 7.0 | 24 | 22.4 | 80 | 355.1 | ||

8 | 8.0 | 25 | 23.8 | 90 | 525.8 | ||

10 | 9.2 | 26 | 25.2 | 95 | 633.9 | ||

12 | 10.5 | 27 | 26.7 | 99 | 733.2 | ||

14 | 12.0 | 28 | 28.3 | 100.0 | 760.0 | ||

16 | 13.6 | 29 | 30.0 | 101.0 | 787.6 |

$${P}_{\text{T}}={P}_{\text{Ar}}+{P}_{{\text{H}}_{2}\text{O}}$$

Rearranging this equation to solve for the pressure of argon gives:

$${P}_{\text{Ar}}={P}_{\text{T}}-{P}_{{\text{H}}_{2}\text{O}}$$

The pressure of water vapor above a sample of liquid water at 26 °C is 25.2 torr, so:

$${P}_{\text{Ar}}=750\phantom{\rule{0.2em}{0ex}}\text{torr}\phantom{\rule{0.2em}{0ex}}-25.2\phantom{\rule{0.2em}{0ex}}\text{torr}=725\phantom{\rule{0.2em}{0ex}}\text{torr}$$

0.583 L

All gases that show ideal behavior contain the same number of molecules in the same volume (at the same temperature and pressure). Thus, the ratios of volumes of gases involved in a chemical reaction are given by the coefficients in the equation for the reaction, provided that the gas volumes are measured at the same temperature and pressure.

We can extend Avogadro’s law (that the volume of a gas is directly proportional to the number of moles of the gas) to chemical reactions with gases: Gases combine, or react, in definite and simple proportions by volume, provided that all gas volumes are measured at the same temperature and pressure. For example, since nitrogen and hydrogen gases react to produce ammonia gas according to ${\text{N}}_{2}(g)+3{\text{H}}_{2}(g)\phantom{\rule{0.4em}{0ex}}\u27f6\phantom{\rule{0.4em}{0ex}}2{\text{NH}}_{3}(g),$ a given volume of nitrogen gas reacts with three times that volume of hydrogen gas to produce two times that volume of ammonia gas, if pressure and temperature remain constant.

The explanation for this is illustrated in Figure 25.4. According to Avogadro’s law, equal volumes of gaseous N_{2}, H_{2}, and NH_{3}, at the same temperature and pressure, contain the same number of molecules. Because one molecule of N_{2} reacts with three molecules of H_{2} to produce two molecules of NH_{3}, the volume of H_{2} required is three times the volume of N_{2}, and the volume of NH_{3} produced is two times the volume of N_{2}.

$$\begin{array}{l}{\text{C}}_{3}{\text{H}}_{8}(g)+5{\text{O}}_{2}(g)\text{\hspace{1em}}\text{\hspace{1em}}\u27f6\text{\hspace{1em}}\text{\hspace{1em}}3{\text{CO}}_{2}(g)+4{\text{H}}_{2}\text{O}\left(l\right)\\ \text{1 volume}+\text{5 volumes}\phantom{\rule{3.5em}{0ex}}\text{3 volumes}+\text{4 volumes}\end{array}$$

From the equation, we see that one volume of C_{3}H_{8} will react with five volumes of O_{2}:

$$2.7\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}\phantom{\rule{0.2em}{0ex}}{\text{C}}_{3}{\text{H}}_{8}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\frac{\text{5 L}\phantom{\rule{0.2em}{0ex}}{\text{O}}_{2}}{1\phantom{\rule{0.2em}{0ex}}\overline{)\text{L}\phantom{\rule{0.2em}{0ex}}{\text{C}}_{3}{\text{H}}_{8}}}\phantom{\rule{0.2em}{0ex}}=\text{13.5 L}\phantom{\rule{0.2em}{0ex}}{\text{O}}_{2}$$

A volume of 13.5 L of O_{2} will be required to react with 2.7 L of C_{3}H_{8}.

$$2{\text{C}}_{2}{\text{H}}_{2}+5{\text{O}}_{2}\phantom{\rule{0.2em}{0ex}}\u27f6\phantom{\rule{0.2em}{0ex}}4{\text{CO}}_{2}+2{\text{H}}_{2}\text{O}$$

3.34 tanks (2.34 $\times $ 10^{4} L)

$${\text{N}}_{2}(g)+3{\text{H}}_{2}(g)\phantom{\rule{0.2em}{0ex}}\u27f6\phantom{\rule{0.2em}{0ex}}2{\text{NH}}_{3}(g)$$

$$683\phantom{\rule{0.2em}{0ex}}\overline{)\text{billion}\phantom{\rule{0.2em}{0ex}}{\text{ft}}^{3}\phantom{\rule{0.2em}{0ex}}{\text{NH}}_{3}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\frac{\text{3 billion}\phantom{\rule{0.2em}{0ex}}{\text{ft}}^{3}\phantom{\rule{0.2em}{0ex}}{\text{H}}_{2}}{2\phantom{\rule{0.2em}{0ex}}\overline{)\text{billion}\phantom{\rule{0.2em}{0ex}}{\text{ft}}^{3}\phantom{\rule{0.2em}{0ex}}{\text{NH}}_{3}}}\phantom{\rule{0.2em}{0ex}}=1.02\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{3}\phantom{\rule{0.2em}{0ex}}\text{billion}\phantom{\rule{0.2em}{0ex}}{\text{ft}}^{3}\phantom{\rule{0.2em}{0ex}}{\text{H}}_{2}$$

The manufacture of 683 billion ft^{3} of NH_{3} required 1020 billion ft^{3} of H_{2}. (At 25 °C and 1 atm, this is the volume of a cube with an edge length of approximately 1.9 miles.)

51.0 L

$$2\text{Ga}\left(s\right)+6\text{HCl}\left(aq\right)\phantom{\rule{0.2em}{0ex}}\u27f6\phantom{\rule{0.2em}{0ex}}2{\text{GaCl}}_{3}\left(aq\right)+3{\text{H}}_{2}(g)$$

Convert the provided mass of the limiting reactant, Ga, to moles of hydrogen produced:

$$8.88\phantom{\rule{0.2em}{0ex}}\overline{)\text{g Ga}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\frac{1\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol Ga}}}{69.723\phantom{\rule{0.2em}{0ex}}\overline{)\text{g Ga}}}\phantom{\rule{0.4em}{0ex}}\times \phantom{\rule{0.4em}{0ex}}\frac{\text{3 mol}\phantom{\rule{0.2em}{0ex}}{\text{H}}_{2}}{2\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol Ga}}}\phantom{\rule{0.2em}{0ex}}=0.191\phantom{\rule{0.2em}{0ex}}{\text{mol H}}_{2}$$

Convert the provided temperature and pressure values to appropriate units (K and atm, respectively), and then use the molar amount of hydrogen gas and the ideal gas equation to calculate the volume of gas:

$$V=\left(\frac{nRT}{P}\right)=\phantom{\rule{0.2em}{0ex}}\frac{0.191\phantom{\rule{0.2em}{0ex}}\overline{)\text{mol}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\text{0.08206 L}\phantom{\rule{0.2em}{0ex}}\overline{)\text{atm}\phantom{\rule{0.2em}{0ex}}{\text{mol}}^{\text{\u22121}}\phantom{\rule{0.2em}{0ex}}{\text{K}}^{\text{\u22121}}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}\text{300 K}}{0.951\phantom{\rule{0.2em}{0ex}}\overline{)\text{atm}}}\phantom{\rule{0.2em}{0ex}}=\text{4.94 L}$$

1.30 $\times $ 10^{3} L

The thin skin of our atmosphere keeps the earth from being an ice planet and makes it habitable. In fact, this is due to less than 0.5% of the air molecules. Of the energy from the sun that reaches the earth, almost $\frac{1}{3}$ is reflected back into space, with the rest absorbed by the atmosphere and the surface of the earth. Some of the energy that the earth absorbs is re-emitted as infrared (IR) radiation, a portion of which passes back out through the atmosphere into space. Most of this IR radiation, however, is absorbed by certain atmospheric gases, effectively trapping heat within the atmosphere in a phenomenon known as the *greenhouse effect*. This effect maintains global temperatures within the range needed to sustain life on earth. Without our atmosphere, the earth's average temperature would be lower by more than 30 °C (nearly 60 °F). The major greenhouse gases (GHGs) are water vapor, carbon dioxide, methane, and ozone. Since the Industrial Revolution, human activity has been increasing the concentrations of GHGs, which have changed the energy balance and are significantly altering the earth’s climate (Figure 25.5).

There is strong evidence from multiple sources that higher atmospheric levels of CO_{2} are caused by human activity, with fossil fuel burning accounting for about $\frac{3}{4}$ of the recent increase in CO_{2}. Reliable data from ice cores reveals that CO_{2} concentration in the atmosphere is at the highest level in the past 800,000 years; other evidence indicates that it may be at its highest level in 20 million years. In recent years, the CO_{2} concentration has increased from preindustrial levels of ~280 ppm to more than 400 ppm today (Figure 25.6).

Watch this video that explains greenhouse gases and global warming:

Atmospheric and climate scientist Susan Solomon (Figure 25.7) is the author of one of *The New York Times* books of the year (*The Coldest March*, 2001), one of Time magazine’s 100 most influential people in the world (2008), and a working group leader of the Intergovernmental Panel on Climate Change (IPCC), which was the recipient of the 2007 Nobel Peace Prize. She helped determine and explain the cause of the formation of the ozone hole over Antarctica, and has authored many important papers on climate change. She has been awarded the top scientific honors in the US and France (the National Medal of Science and the Grande Medaille, respectively), and is a member of the National Academy of Sciences, the Royal Society, the French Academy of Sciences, and the European Academy of Sciences. Formerly a professor at the University of Colorado, she is now at MIT, and continues to work at NOAA.

For more information, watch this video about Susan Solomon:

Link to Supplemental Exercises

Supplemental exercises are available if you would like more practice with these concepts.

Supplemental exercises are available if you would like more practice with these concepts.

By the end of this section, you will be able to:

- Define and explain effusion and diffusion
- State Graham’s law and use it to compute relevant gas properties

If you have ever been in a room when a piping hot pizza was delivered, you have been made aware of the fact that gaseous molecules can quickly spread throughout a room, as evidenced by the pleasant aroma that soon reaches your nose. Although gaseous molecules travel at tremendous speeds (hundreds of meters per second), they collide with other gaseous molecules and travel in many different directions before reaching the desired target. At room temperature, a gaseous molecule will experience billions of collisions per second. The mean free path is the average distance a molecule travels between collisions. The mean free path increases with decreasing pressure; in general, the mean free path for a gaseous molecule will be hundreds of times the diameter of the molecule

In general, we know that when a sample of gas is introduced to one part of a closed container, its molecules very quickly disperse throughout the container; this process by which molecules disperse in space in response to differences in concentration is called diffusion (shown in Figure 25.8). The gaseous atoms or molecules are, of course, unaware of any concentration gradient, they simply move randomly—regions of higher concentration have more particles than regions of lower concentrations, and so a net movement of species from high to low concentration areas takes place. In a closed environment, diffusion will ultimately result in equal concentrations of gas throughout, as depicted in Figure 25.8. The gaseous atoms and molecules continue to move, but since their concentrations are the same in both bulbs, the rates of transfer between the bulbs are equal (no *net* transfer of molecules occurs).

We are often interested in the rate of diffusion, the amount of gas passing through some area per unit time:

$$\text{rate of diffusion}=\phantom{\rule{0.2em}{0ex}}\frac{\text{amount of gas passing through an area}}{\text{unit of time}}$$

The diffusion rate depends on several factors: the concentration gradient (the increase or decrease in concentration from one point to another); the amount of surface area available for diffusion; and the distance the gas particles must travel. Note also that the time required for diffusion to occur is inversely proportional to the rate of diffusion, as shown in the rate of diffusion equation.

A process involving movement of gaseous species similar to diffusion is effusion, the escape of gas molecules through a tiny hole such as a pinhole in a balloon into a vacuum (Figure 25.9). Although diffusion and effusion rates both depend on the molar mass of the gas involved, their rates are not equal; however, the ratios of their rates are the same.

If a mixture of gases is placed in a container with porous walls, the gases effuse through the small openings in the walls. The lighter gases pass through the small openings more rapidly (at a higher rate) than the heavier ones (Figure 25.10). In 1832, Thomas Graham studied the rates of effusion of different gases and formulated Graham’s law of effusion: *The rate of effusion of a gas is inversely proportional to the square root of the mass of its particles*:

$$\text{rate of effusion}\propto \frac{1}{\sqrt{\text{\mathcal{M}}}}$$

This means that if two gases A and B are at the same temperature and pressure, the ratio of their effusion rates is inversely proportional to the ratio of the square roots of the masses of their particles:

$$\frac{\text{rate of effusion of A}}{\text{rate of effusion of B}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{\text{B}}}}{\sqrt{{\text{\mathcal{M}}}_{\text{A}}}}$$

$$\frac{\text{rate of effusion of hydrogen}}{\text{rate of effusion of oxygen}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{32\phantom{\rule{0.2em}{0ex}}\overline{){\text{g mol}}^{\text{\u22121}}}}}{\sqrt{2\phantom{\rule{0.2em}{0ex}}\overline{){\text{g mol}}^{\text{\u22121}}}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{16}}{\sqrt{1}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{4}{1}$$

Hydrogen effuses four times as rapidly as oxygen.

52 mL/s

$$\text{rate of effusion}=\phantom{\rule{0.2em}{0ex}}\frac{\text{amount of gas transferred}}{\text{time}}$$

and combine it with Graham’s law:

$$\frac{\text{rate of effusion of gas Xe}}{\text{rate of effusion of gas Ne}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{\text{Ne}}}}{\sqrt{{\text{\mathcal{M}}}_{\text{Xe}}}}$$

To get:

$$\frac{\frac{\text{amount of Xe transferred}}{\text{time for Xe}}}{\frac{\text{amount of Ne transferred}}{\text{time for Ne}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{\text{Ne}}}}{\sqrt{{\text{\mathcal{M}}}_{\text{Xe}}}}$$

Noting that *amount of A* = *amount of B*, and solving for *time for Ne*:

$$\frac{\frac{\overline{)\text{amount of Xe}}}{\text{time for Xe}}}{\frac{\overline{)\text{amount of Ne}}}{\text{time for Ne}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\text{time for Ne}}{\text{time for Xe}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{\text{Ne}}}}{\sqrt{{\text{\mathcal{M}}}_{\text{Xe}}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{\text{Ne}}}}{\sqrt{{\text{\mathcal{M}}}_{\text{Xe}}}}$$

and substitute values:

$$\frac{\text{time for Ne}}{243\phantom{\rule{0.2em}{0ex}}\text{s}}\phantom{\rule{0.2em}{0ex}}=\sqrt{\frac{20.2\phantom{\rule{0.2em}{0ex}}\overline{)\text{g mol}}}{131.3\phantom{\rule{0.2em}{0ex}}\overline{)\text{g mol}}}}\phantom{\rule{0.2em}{0ex}}=0.392$$

Finally, solve for the desired quantity:

$$\text{time for Ne}=0.392\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}243\phantom{\rule{0.2em}{0ex}}\text{s}=95.3\phantom{\rule{0.2em}{0ex}}\text{s}$$

Note that this answer is reasonable: Since Ne is lighter than Xe, the effusion rate for Ne will be larger than that for Xe, which means the time of effusion for Ne will be smaller than that for Xe.

32 h

$$\frac{\text{rate of effusion of Unknown}}{{\text{rate of effusion of CO}}_{2}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{{\text{\mathcal{M}}}_{{\text{CO}}_{2}}}}{\sqrt{{\text{\mathcal{M}}}_{Unknown}}}$$

Plug in known data:

$$\frac{1.66}{1}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{\sqrt{44.0\phantom{\rule{0.2em}{0ex}}\text{g/mol}}}{\sqrt{{\text{\mathcal{M}}}_{Unknown}}}$$

Solve:

$${\text{\mathcal{M}}}_{Unknown}=\phantom{\rule{0.2em}{0ex}}\frac{44.0\phantom{\rule{0.2em}{0ex}}\text{g/mol}}{{(1.66)}^{2}}\phantom{\rule{0.2em}{0ex}}=16.0\phantom{\rule{0.2em}{0ex}}\text{g/mol}$$

The gas could well be CH_{4}, the only gas with this molar mass.

163 g/mol

Gaseous diffusion has been used to produce enriched uranium for use in nuclear power plants and weapons. Naturally occurring uranium contains only 0.72% of ^{235}U, the kind of uranium that is “fissile,” that is, capable of sustaining a nuclear fission chain reaction. Nuclear reactors require fuel that is 2–5% ^{235}U, and nuclear bombs need even higher concentrations. One way to enrich uranium to the desired levels is to take advantage of Graham’s law. In a gaseous diffusion enrichment plant, uranium hexafluoride (UF_{6}, the only uranium compound that is volatile enough to work) is slowly pumped through large cylindrical vessels called diffusers, which contain porous barriers with microscopic openings. The process is one of diffusion because the other side of the barrier is not evacuated. The ^{235}UF_{6} molecules have a higher average speed and diffuse through the barrier a little faster than the heavier ^{238}UF_{6} molecules. The gas that has passed through the barrier is slightly enriched in ^{235}UF_{6} and the residual gas is slightly depleted. The small difference in molecular weights between ^{235}UF_{6} and ^{238}UF_{6} only about 0.4% enrichment, is achieved in one diffuser (Figure 25.11). But by connecting many diffusers in a sequence of stages (called a cascade), the desired level of enrichment can be attained.

The large scale separation of gaseous ^{235}UF_{6} from ^{238}UF_{6} was first done during the World War II, at the atomic energy installation in Oak Ridge, Tennessee, as part of the Manhattan Project (the development of the first atomic bomb). Although the theory is simple, this required surmounting many daunting technical challenges to make it work in practice. The barrier must have tiny, uniform holes (about 10^{–6} cm in diameter) and be porous enough to produce high flow rates. All materials (the barrier, tubing, surface coatings, lubricants, and gaskets) need to be able to contain, but not react with, the highly reactive and corrosive UF_{6}.

Because gaseous diffusion plants require very large amounts of energy (to compress the gas to the high pressures required and drive it through the diffuser cascade, to remove the heat produced during compression, and so on), it is now being replaced by gas centrifuge technology, which requires far less energy. A current hot political issue is how to deny this technology to Iran, to prevent it from producing enough enriched uranium for them to use to make nuclear weapons.

Supplemental exercises are available if you would like more practice with these concepts.

By the end of this section, you will be able to:

- Describe the effects of temperature and pressure on solubility
- State Henry’s law and use it in calculations involving the solubility of a gas in a liquid

Imagine adding a small amount of sugar to a glass of water, stirring until all the sugar has dissolved, and then adding a bit more. You can repeat this process until the sugar concentration of the solution reaches its natural limit, a limit determined primarily by the relative strengths of the solute-solute, solute-solvent, and solvent-solvent attractive forces discussed in the previous two modules of this chapter. You can be certain that you have reached this limit because, no matter how long you stir the solution, undissolved sugar remains. The concentration of sugar in the solution at this point is known as its solubility.

The solubility of a solute in a particular solvent is the maximum concentration that may be achieved under given conditions when the dissolution process is *at equilibrium*.

When a solute’s concentration is equal to its solubility, the solution is said to be saturated with that solute. If the solute’s concentration is less than its solubility, the solution is said to be unsaturated. A solution that contains a relatively low concentration of solute is called dilute, and one with a relatively high concentration is called concentrated.

Use this interactive simulation to prepare various saturated solutions.

Solutions may be prepared in which a solute concentration *exceeds* its solubility. Such solutions are said to be supersaturated, and they are interesting examples of *nonequilibrium* states (a detailed treatment of this important concept is provided in the text chapters on equilibrium). For example, the carbonated beverage in an open container that has not yet “gone flat” is supersaturated with carbon dioxide gas; given time, the CO_{2} concentration will decrease until it reaches its solubility.

Watch this impressive video showing the precipitation of sodium acetate from a supersaturated solution.

As for any solution, the solubility of a gas in a liquid is affected by the intermolecular attractive forces between solute and solvent species. Unlike solid and liquid solutes, however, there is no solute-solute intermolecular attraction to overcome when a gaseous solute dissolves in a liquid solvent since the atoms or molecules comprising a gas are far separated and experience negligible interactions. Consequently, solute-solvent interactions are the sole energetic factor affecting solubility. For example, the water solubility of oxygen is approximately three times greater than that of helium (there are greater dispersion forces between water and the larger oxygen molecules) but 100 times less than the solubility of chloromethane, CHCl_{3} (polar chloromethane molecules experience dipole–dipole attraction to polar water molecules). Likewise note the solubility of oxygen in hexane, C_{6}H_{14}, is approximately 20 times greater than it is in water because greater dispersion forces exist between oxygen and the larger hexane molecules.

Temperature is another factor affecting solubility, with gas solubility typically decreasing as temperature increases (Figure 25.12). This inverse relation between temperature and dissolved gas concentration is responsible for one of the major impacts of thermal pollution in natural waters.

When the temperature of a river, lake, or stream is raised, the solubility of oxygen in the water is decreased. Decreased levels of dissolved oxygen may have serious consequences for the health of the water’s ecosystems and, in severe cases, can result in large-scale fish kills (Figure 25.13).

The solubility of a gaseous solute is also affected by the partial pressure of solute in the gas to which the solution is exposed. Gas solubility increases as the pressure of the gas increases. Carbonated beverages provide a nice illustration of this relationship. The carbonation process involves exposing the beverage to a relatively high pressure of carbon dioxide gas and then sealing the beverage container, thus saturating the beverage with CO_{2} at this pressure. When the beverage container is opened, a familiar hiss is heard as the carbon dioxide gas pressure is released, and some of the dissolved carbon dioxide is typically seen leaving solution in the form of small bubbles (Figure 25.14). At this point, the beverage is *supersaturated* with carbon dioxide and, with time, the dissolved carbon dioxide concentration will decrease to its equilibrium value and the beverage will become “flat.”

For many gaseous solutes, the relation between solubility, *C*_{g}, and partial pressure, *P*_{g}, is a proportional one:

$${C}_{\text{g}}=k{P}_{\text{g}}$$

where *k* is a proportionality constant that depends on the identity of the gaseous solute, the identity of the solvent, and the solution temperature. This is a mathematical statement of Henry’s law: *The quantity of an ideal gas that dissolves in a definite volume of liquid is directly proportional to the pressure of the gas.*

$$\begin{array}{ccc}\hfill {C}_{\text{g}}& =& k{P}_{\text{g}}\hfill \\ \hfill k& =& \phantom{\rule{0.2em}{0ex}}\frac{{C}_{\text{g}}}{{P}_{\text{g}}}\hfill \\ & =& \phantom{\rule{0.2em}{0ex}}\frac{1.38\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-3}}\phantom{\rule{0.2em}{0ex}}\text{mol}\phantom{\rule{0.2em}{0ex}}{\text{L}}^{\mathrm{-1}}}{101.3\phantom{\rule{0.2em}{0ex}}\text{kPa}}\hfill \\ & =& 1.36\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-5}}\phantom{\rule{0.2em}{0ex}}\text{mol}\phantom{\rule{0.2em}{0ex}}{\text{L}}^{\mathrm{-1}}\phantom{\rule{0.2em}{0ex}}{\text{kPa}}^{\mathrm{-1}}\hfill \end{array}$$

Now, use *k* to find the solubility at the lower pressure.

$$\begin{array}{cccc}& \hfill {C}_{\text{g}}& =& k{P}_{\text{g}}\hfill \\ & & & 1.36\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-5}}\phantom{\rule{0.2em}{0ex}}\text{mol}\phantom{\rule{0.2em}{0ex}}{\text{L}}^{\mathrm{-1}}\phantom{\rule{0.2em}{0ex}}{\text{kPa}}^{\mathrm{-1}}\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}20.7\phantom{\rule{0.2em}{0ex}}\text{kPa}\hfill \\ & & =& 2.82\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-4}}\phantom{\rule{0.2em}{0ex}}\text{mol}\phantom{\rule{0.2em}{0ex}}{\text{L}}^{\mathrm{-1}}\hfill \end{array}$$

Note that various units may be used to express the quantities involved in these sorts of computations. Any combination of units that yield to the constraints of dimensional analysis are acceptable.

7.25 $\times $ 10^{−3} in 100.0 mL or 0.0725 g/L

$$k\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}\frac{{C}_{\text{g}}}{{P}_{\text{g}}}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}1.2\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-3}}\phantom{\rule{0.2em}{0ex}}\text{mol/L/1.00 atm}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}1.2\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-3}}\phantom{\rule{0.2em}{0ex}}\text{mol/L atm}$$

Then, use this *k* value to compute the oxygen solubility at the specified oxygen partial pressure, 0.17 atm.

$${C}_{g}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}{kP}_{g}\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}(1.2\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-3}}\phantom{\rule{0.2em}{0ex}}\text{mol/L atm})\phantom{\rule{0.2em}{0ex}}(0.17\phantom{\rule{0.2em}{0ex}}\text{atm})\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}2.0\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-4}}\phantom{\rule{0.2em}{0ex}}\text{mol/L}$$

Finally, convert this dissolved oxygen concentration from mol/L to mg/L.

$$(2.0\phantom{\rule{0.2em}{0ex}}\times \phantom{\rule{0.2em}{0ex}}{10}^{\mathrm{-4}}\phantom{\rule{0.2em}{0ex}}\text{mol/L})\phantom{\rule{0.2em}{0ex}}(32.0\phantom{\rule{0.2em}{0ex}}\text{g/1 mol})\phantom{\rule{0.2em}{0ex}}(1000\phantom{\rule{0.2em}{0ex}}\text{mg/g})\phantom{\rule{0.2em}{0ex}}=\phantom{\rule{0.2em}{0ex}}6.4\phantom{\rule{0.2em}{0ex}}\text{mg/L}.$$

This concentration is lesser than the required minimum value of 7.5 mg/L, and so these trout would likely not thrive in the polluted stream.

8.2 mg/L

Decompression sickness (DCS), or “the bends,” is an effect of the increased pressure of the air inhaled by scuba divers when swimming underwater at considerable depths. In addition to the pressure exerted by the atmosphere, divers are subjected to additional pressure due to the water above them, experiencing an increase of approximately 1 atm for each 10 m of depth. Therefore, the air inhaled by a diver while submerged contains gases at the corresponding higher ambient pressure, and the concentrations of the gases dissolved in the diver’s blood are proportionally higher per Henry’s law.

As the diver ascends to the surface of the water, the ambient pressure decreases and the dissolved gases becomes less soluble. If the ascent is too rapid, the gases escaping from the diver’s blood may form bubbles that can cause a variety of symptoms ranging from rashes and joint pain to paralysis and death. To avoid DCS, divers must ascend from depths at relatively slow speeds (10 or 20 m/min) or otherwise make several decompression stops, pausing for several minutes at given depths during the ascent. When these preventive measures are unsuccessful, divers with DCS are often provided hyperbaric oxygen therapy in pressurized vessels called decompression (or recompression) chambers (Figure 25.15). Researchers are also investigating related body reactions and defenses in order to develop better testing and treatment for decompression sicknetss. For example, Ingrid Eftedal, a barophysiologist specializing in bodily reactions to diving, has shown that white blood cells undergo chemical and genetic changes as a result of the condition; these can potentially be used to create biomarker tests and other methods to manage decompression sickness.

Deviations from Henry’s law are observed when a chemical reaction takes place between the gaseous solute and the solvent. Thus, for example, the solubility of ammonia in water increases more rapidly with increasing pressure than predicted by the law because ammonia, being a base, reacts to some extent with water to form ammonium ions and hydroxide ions.

Gases can form supersaturated solutions. If a solution of a gas in a liquid is prepared either at low temperature or under pressure (or both), then as the solution warms or as the gas pressure is reduced, the solution may become supersaturated. In 1986, more than 1700 people in Cameroon were killed when a cloud of gas, almost certainly carbon dioxide, bubbled from Lake Nyos (Figure 25.16), a deep lake in a volcanic crater. The water at the bottom of Lake Nyos is saturated with carbon dioxide by volcanic activity beneath the lake. It is believed that the lake underwent a turnover due to gradual heating from below the lake, and the warmer, less-dense water saturated with carbon dioxide reached the surface. Consequently, tremendous quantities of dissolved CO_{2} were released, and the colorless gas, which is denser than air, flowed down the valley below the lake and suffocated humans and animals living in the valley.

Supplemental exercises are available if you would like more practice with these concepts.
