- Predict the response of a stressed equilibrium using Le Châtelier’s principle

Consistent with the law of mass action, an equilibrium stressed by a change in concentration will shift to re-establish equilibrium without any change in the value of the equilibrium constant, *K*. When an equilibrium shifts in response to a temperature change, however, it is re-established with a different relative composition that exhibits a different value for the equilibrium constant.

To understand this phenomenon, consider the elementary reaction

$$\text{A}\rightleftharpoons \text{B}$$

Since this is an elementary reaction, the rates laws for the forward and reverse may be derived directly from the balanced equation’s stoichiometry:

$$\begin{array}{c}{\text{rate}}_{f}={k}_{f}[\text{A}]\hfill \\ {\text{rate}}_{r}={k}_{r}[\text{B}]\hfill \end{array}$$

When the system is at equilibrium,

$${\text{rate}}_{r}={\text{rate}}_{f}$$

Substituting the rate laws into this equality and rearranging gives

$$\begin{array}{ccc}\hfill {k}_{f}[\text{A}]& =\hfill & {k}_{r}[\text{B}]\hfill \\ \hfill \frac{[\text{B}]}{[\text{A}]}& =\hfill & \frac{{k}_{f}}{{k}_{r}}={K}_{c}\hfill \end{array}$$

The equilibrium constant is seen to be a mathematical function of the rate constants for the forward and reverse reactions. Since the rate constants vary with temperature as described by the Arrhenius equation, is stands to reason that the equilibrium constant will likewise vary with temperature (assuming the rate constants are affected to different extents by the temperature change). For more complex reactions involving multistep reaction mechanisms, a similar but more complex mathematical relation exists between the equilibrium constant and the rate constants of the steps in the mechanism. Regardless of how complex the reaction may be, the temperature-dependence of its equilibrium constant persists.

Predicting the shift an equilibrium will experience in response to a change in temperature is most conveniently accomplished by considering the enthalpy change of the reaction. For example, the decomposition of dinitrogen tetroxide is an endothermic (heat-consuming) process:

$${\text{N}}_{2}{\text{O}}_{4}(g)\rightleftharpoons 2{\text{NO}}_{2}(g)\phantom{\rule{5em}{0ex}}\text{\Delta}H=57.20\phantom{\rule{0.2em}{0ex}}\text{kJ}$$

For purposes of applying Le Chatelier’s principle, heat (*q*) may be viewed as a reactant:

$$\text{heat}+{\text{N}}_{2}{\text{O}}_{4}(g)\rightleftharpoons 2{\text{NO}}_{2}(g)$$

Raising the temperature of the system is akin to increasing the amount of a reactant, and so the equilibrium will shift to the right. Lowering the system temperature will likewise cause the equilibrium to shift left. For exothermic processes, heat is viewed as a product of the reaction and so the opposite temperature dependence is observed.

The value of ${K}_{p}$ is independent of pressure, although the composition of a system at equilibrium may be very much dependent on pressure. Temperature dependence is another matter. Because the value of ${K}_{p}$ is dependent on temperature, the value of $K$ is as well. The form of the temperature dependence can be taken from the definition of the Gibbs function. At constant temperature and pressure

ΔGoT2T2−ΔGoT1T1=ΔHo(1T2−1T1)

Substituting

ΔGo=−RTlnK

For the two values of $\mathrm{ln}(K)$ and using the appropriate temperatures, yields

−RT2lnK2T2−−RT1lnK1T1=ΔHo(1T2−1T1)

And simplifying the expression so that only terms involving $\u2013\mathrm{\Delta}{H}^{o}/R$ are on the left and all other terms are on the right results in the **van ’t Hoff equation**, which describes the temperature dependence of the equilibrium constant.

ln( K2 K1)=−ΔHoR(1T2−1T1)

Because of the assumptions made in the derivation of the Gibbs-Helmholtz equation, this relationship only holds if $\mathrm{\Delta}{H}_{rxm}^{o}=32.4\phantom{\rule{thinmathspace}{0ex}}kJ/mol$ is independent of temperature over the range being considered. This expression also suggests that a plot of $\mathrm{\Delta}{H}_{rxm}^{o}=32.4\phantom{\rule{thinmathspace}{0ex}}kJ/mol$ as a function of $$\begin{array}{rl}\mathrm{ln}\left({\displaystyle \frac{\text{}{K}_{2}}{0.0260}}\right)& =-{\displaystyle \frac{32400\phantom{\rule{thinmathspace}{0ex}}J/mol}{8.314\phantom{\rule{thinmathspace}{0ex}}K/(mol\phantom{\rule{thinmathspace}{0ex}}K)}}({\displaystyle \frac{1}{310\phantom{\rule{thinmathspace}{0ex}}K}}-{\displaystyle \frac{1}{298\phantom{\rule{thinmathspace}{0ex}}K}})\\ {K}_{2}& =0.0431\end{array}$$ should produce a straight line with a slope equal to $\text{P}-\text{Cl}$. Such a plot is known as a **van ’t Hoff plot**, and can be used to determine the reaction enthalpy.

A certain reaction has a value of $${\text{PCl}}_{5}^{\phantom{\rule[-.2em]{0pt}{0pt}}}\rightleftharpoons {\text{PCl}}_{3}^{\phantom{\rule[-.2em]{0pt}{0pt}}}+{\text{Cl}}_{2}^{\phantom{\rule[-.2em]{0pt}{0pt}}}$$ at 25 °C and $\mathrm{\Delta}{H}_{rxm}^{o}=32.4\phantom{\rule{thinmathspace}{0ex}}kJ/mol$. Calculate the value of $\mathrm{\Delta}{H}_{rxm}^{o}=32.4\phantom{\rule{thinmathspace}{0ex}}kJ/mol$ at 37 °C.

This is a job for the van ’t Hoff equation!

- T
_{1}= 298 K - T
_{2 }= 310 K - $$\begin{array}{rl}\mathrm{ln}\left({\displaystyle \frac{\text{}{K}_{2}}{0.0260}}\right)& =-{\displaystyle \frac{32400\phantom{\rule{thinmathspace}{0ex}}J/mol}{8.314\phantom{\rule{thinmathspace}{0ex}}K/(mol\phantom{\rule{thinmathspace}{0ex}}K)}}({\displaystyle \frac{1}{310\phantom{\rule{thinmathspace}{0ex}}K}}-{\displaystyle \frac{1}{298\phantom{\rule{thinmathspace}{0ex}}K}})\\ {K}_{2}& =0.0431\end{array}$$
- K
_{1}= 0.0260 - K
_{2}= ?

So Equation $\text{P}-\text{Cl}$ becomes

$${\text{PCl}}_{5}^{\phantom{\rule[-.2em]{0pt}{0pt}}}\rightleftharpoons {\text{PCl}}_{3}^{\phantom{\rule[-.2em]{0pt}{0pt}}}+{\text{Cl}}_{2}^{\phantom{\rule[-.2em]{0pt}{0pt}}}$$

Note: the value of ${K}_{2}$ **increased **with **increasing **temperature, which is what is expected for an **endothermic **reaction. An increase in temperature should result in an increase of product formation in the equilibrium mixture. But unlike a change in pressure, a change in temperature actually leads to a change in the value of the equilibrium constant!

Given the following average bond enthalpies for $${\text{PCl}}_{5}^{\phantom{\rule[-.2em]{0pt}{0pt}}}\rightleftharpoons {\text{PCl}}_{3}^{\phantom{\rule[-.2em]{0pt}{0pt}}}+{\text{Cl}}_{2}^{\phantom{\rule[-.2em]{0pt}{0pt}}}$$ and $\text{Cl}-\text{Cl}$ bonds, predict whether or not an increase in temperature will lead to a larger or smaller degree of dissociation for the reaction

$${\text{PCl}}_{5}^{\phantom{\rule[-.2em]{0pt}{0pt}}}\rightleftharpoons {\text{PCl}}_{3}^{\phantom{\rule[-.2em]{0pt}{0pt}}}+{\text{Cl}}_{2}^{\phantom{\rule[-.2em]{0pt}{0pt}}}$$

X-Y | D(X-Y) (kJ/mol) |
---|---|

P-Cl | 326 |

Cl-Cl | 240 |

The estimated reaction enthalpy is given by the total energy expended breaking bonds minus the energy recovered by the formation of bonds. Since this reaction involves breaking two P-Cl bonds (costing 652 kJ/mol) and the formation of one Cl-Cl bond (recovering 240 kJ/mol), it is clear that the reaction is endothermic (by approximately 412 kJ/mol). As such, an increase in temperature should increase the value of the equilibrium constant, causing the degree of dissociation to be increased at the higher temperature.

For a reversible reaction, the equilibrium constant can be measured at a variety of temperatures. This data can be plotted on a graph with ln *K*_{eq} on the *y*-axis and 1/*T* on the *x-axis*. The data should have a linear relationship, the equation for which can be found by fitting the data using the linear form of the Van 't Hoff equation

This graph is called the "Van 't Hoff plot" and is widely used to estimate the enthalpy and entropy of a chemical reaction. From this plot, −Δ_{r}*H*/*R* is the slope, and Δ_{r}*S*/*R* is the intercept of the linear fit.

By measuring the equilibrium constant, *K*_{eq}, at different temperatures, the Van 't Hoff plot can be used to assess a reaction when the temperature changes.^{[7]}^{[8]} Knowing the slope and intercept from the Van 't Hoff plot, the enthalpy, and entropy of a reaction can be easily obtained using

The Van 't Hoff plot can be used to quickly determine the enthalpy of a chemical reaction both qualitatively and quantitatively. This change in enthalpy can be positive or negative, leading to two major forms of the Van 't Hoff plot.

For an endothermic reaction, heat is absorbed, making the net enthalpy change positive. Thus, according to the definition of the slope:

When the reaction is endothermic, Δ_{r}*H* > 0 (and the gas constant *R* > 0), so

Thus, for an endothermic reaction, the Van 't Hoff plot should always have a negative slope.

Figure 21.1

*Van 't Hoff plot for an endothermic reaction*

For an exothermic reaction, heat is released, making the net enthalpy change negative. Thus, according to the definition of the slope:

For an exothermic reaction Δ_{r}*H* < 0, so

Thus, for an exothermic reaction, the Van 't Hoff plot should always have a positive slope.

figure 20.2

*Van 't Hoff plot for an exothermic reaction*

At first glance, using the fact that Δ_{r}*G*^{⊖} = −*RT* ln *K* = Δ_{r}*H*^{⊖} − *T*Δ_{r}*S*^{⊖} it would appear that two measurements of *K* would suffice to be able to obtain an accurate value of Δ_r*H*^{⊖}:

where *K*_{1} and *K*_{2} are the equilibrium constant values obtained at temperatures *T*_{1} and *T*_{2} respectively. However, the precision of Δ_{r}*H*^{⊖} values obtained in this way is highly dependent on the precision of the measured equilibrium constant values.

The use of error propagation shows that the error in Δ_{r}*H*^{⊖} will be about 76 kJ/mol times the experimental uncertainty in (ln *K*_{1} − ln *K*_{2}), or about 110 kJ/mol times the uncertainty in the ln *K* values. Similar considerations apply to the entropy of reaction obtained from Δ_{r}*S*^{⊖} = 1/*T*(Δ*H*^{⊖} + *RT* ln *K*).

Notably, when equilibrium constants are measured at three or more temperatures, values of Δ_{r}*H*^{⊖} and Δ_{r}*S*^{⊖} are often obtained by straight-line fitting.^{[9]} The expectation is that the error will be reduced by this procedure, although the assumption that the enthalpy and entropy of reaction are constant may or may not prove to be correct. If there is significant temperature dependence in either or both quantities, it should manifest itself in nonlinear behavior in the Van t'Hoff plot; however, more than three data points would presumably be needed in order to observe this.
